Qingdao Tune Technology Co., Ltd. builds Piaggio APE Carts at its 4,500-square-meter production site in Shandong, China. The Piaggio APE is a three-wheeled Italian light commercial vehicle that has been adapted into a mobile vending platform for coffee, cocktails, gelato, and street food. TUNE offers both the classic petrol version and an electric version, with custom bodywork and interior fit-out. Width is under 1.5 meters, so the cart can fit through narrow streets and indoor entrances that full-size trucks cannot access.
The overall width is under 1.5 meters with a turning radius under 3.5 meters. The three-wheeled layout places one steering wheel at the front and a rigid rear axle at the back, which distributes load evenly. This makes the cart suitable for cobblestone lanes, pedestrian precincts, market alleys, and indoor exhibition halls. It can park and trade in spaces that are closed to normal vans and towed trailers.
The Piaggio Ape Classic Cart uses a rounded cab nose, twin retro headlights, chrome side mirrors, and gas-strut gull-wing doors that open on three sides. The fiberglass shell is finished in automotive-grade polyurethane paint, which resists UV and rain and can be color-matched to your brand. Other body styles are available, including open-counter and enclosed configurations, depending on the menu and the market.
The chassis is a cold-rolled steel box frame with cathodic dip electrocoating to protect against humidity, road salt, and dirt. Front suspension uses hydraulic telescopic shocks. The rear uses heavy-duty leaf springs with trailing arms. This setup keeps the vehicle stable when carrying a rear payload of up to about 500 kg, which is enough for espresso machines, refrigeration modules, or beverage kegs.
The petrol version uses the standard Piaggio APE drivetrain. The Piaggio Electric Cart uses a 72V 7.5kW AC induction motor with a 150Ah LiFePO4 battery pack. Top speed is about 40 km/h, and range is 70 to 90 km per charge. An onboard 110V-240V smart charger brings the battery to full in about 6 hours from a standard outlet. The electric version produces no local exhaust, which allows trading inside malls, exhibition halls, and low-emission urban zones.
The rear vending bay can be configured with food-grade brushed metal worktops, under-counter cabinets, and non-slip aluminum checker-plate flooring with drainage plugs. Equipment slides are rated for 80 kg and can hold dual-group espresso machines, soft-serve freezers, griddles, or multi-tap draft towers. Counter height and drawer positions are adjusted to the operator's working height so the layout remains usable during busy service.
Each cart includes an IP65 external shore-power inlet (16A or 32A) connected to a central breaker panel with residual current device protection. For off-grid use, the auxiliary circuit can be paired with a 3000W pure sine wave inverter and a secondary 24V deep-cycle battery bank. This supports payment terminals, LED lighting, and refrigeration during extended outdoor shifts without relying on a generator.
The wash station uses dual 30L removable HDPE tanks for fresh water and greywater. A 12V micro-diaphragm pump runs at 35 PSI and feeds a compact stainless steel sink with a folding swivel faucet and a soap dispenser. A 12V or 110V inline heater provides warm water at about 50°C for handwashing. The tanks can be removed for refilling and cleaning, which is useful at venues without a fixed water point.
The Piaggio APE Cart is used for espresso, prosecco, craft beer, cold brew, gelato, sorbet, crepes, and small-plate service. It appears at weddings, corporate events, seaside promenades, municipal parks, resort plazas, and brand activations. For menus that need a larger kitchen footprint, a Food Trailer may be a better fit.
Before dispatch, each cart goes through chassis balance checks, brake force testing, and electrical insulation testing. Units are run over simulated rough terrain, and all gull-wing hatches are checked with high-pressure water spray. Finished carts are secured in export-grade plywood crates with reinforced corner blocking for ocean freight. TUNE provides a 12-month structural warranty and stocks common spares such as water pumps, faucets, brake parts, and electrical switches.
Piaggio APE Carts can be supplied with CE, ISO 9001, DOT, EPR, COC, and NSF-aligned documents where required. TUNE holds Alibaba Gold Supplier status and has completed regular third-party inspections by SGS and Intertek. Certificate numbers, scope, and validity can be provided before ordering.
Q: Is the Piaggio APE Cart road legal in my country?
A: Rules vary by market. Some countries register the APE as a light commercial vehicle. Others treat it as a slow vehicle or restrict it to private sites. Share your destination and we can advise on the correct configuration and documents.
Q: Petrol or electric — which should I choose?
A: Petrol suits long routes and areas without charging access. Electric suits indoor venues, low-emission zones, and short daily routes up to about 70-90 km per charge. Both can be fitted with the same interior equipment.
Q: How much payload can it carry?
A: The rear bay is rated for about 500 kg of payload. Final capacity depends on the equipment fitted and the local road rules for the vehicle class.
Q: What is the lead time for a custom build?
A: Lead time depends on body style, equipment, and finish. After drawings and deposit are confirmed, most builds take several weeks to a few months. The exact schedule is written into the order.
Q: What after-sales support is included?
A: TUNE offers a 12-month structural warranty, remote technical support, and shipment of common spare parts. Specific terms are stated in the contract.
