Qingdao Tune Technology Co., Ltd. builds Vintage Pedal Food Bikes at its 4,500-square-meter production site in Shandong, China. This is a pedal-driven vending tricycle with a retro European design. It uses hand-finished ash hardwood trim, polished brass accents, a chromoly steel frame, and a food-grade 304 stainless steel storage module. The bike is used at weddings, luxury resorts, historic squares, and pop-up bars. A motorized version with the same body style is listed under Electric Food Bike, and larger towable units are covered by Food Trailer.
The main frame is TIG-welded 4130 chromoly steel tubing with reinforced lugged fork joints and a low center of gravity. It is built to carry a total commercial payload of 220 kg. The drivetrain uses a Shimano 7-speed internal gear hub with dual 180 mm front mechanical disc brakes and a rear coaster brake. A parking pawl lock on the handlebar levers secures all three wheels when the bike is stationary, which prevents rolling during sales on sloped surfaces. The internal hub avoids external derailleur damage and reduces maintenance to periodic lubrication.
The Classic Pedal Ice Cream Cart Bike uses a 300L freezer chest lined with 45 mm high-density polyurethane insulation. Pre-frozen eutectic holdover plates keep up to 12 standard 5L gelato pans between -18°C and -22°C for up to 9 hours. The system does not need a generator or grid power, so it suits summer festivals, beachfront boardwalks, and garden events. The chest lid opens on gas struts, and the counter surface is stainless steel.
The Vintage Beverage & Cocktail Tap Bike holds twin 19L NSF-certified stainless steel Cornelius kegs and a 10L CO2 tank in a vibration-damped bracket. Liquid lines run through insulated glycol-trace cooling jackets to a dual-faucet polished brass tap tower mounted on the wooden counter. This allows draft beer, prosecco, cider, or cold-brew coffee to be poured at 3°C to 5°C without an electrical outlet. The gas system is pressure-tested before shipment.
The Lightweight Push & Pedal Snack Bike weighs 68 kg empty, measures 1,950 mm long and 880 mm wide, and uses a quick-release front steering pivot. The rider can pedal to the site, then disengage the drive pin and push the unit through indoor trade show halls or crowded venues. It comes with a fold-out side prep shelf, acrylic bakery bins, and an overhead canvas awning. This configuration is used for high-volume snack orders in space-restricted layouts.
The exterior ash wood paneling is treated with marine-grade clear spar varnish, which protects against UV degradation, humidity expansion, and salt air. Brass trim rails are 1.5 mm solid brass and hand-polished. The frame receives a multi-stage zinc-phosphate wash and a baked thermosetting powder coat to resist rust and acidic beverage spills. The 28-inch retro spoke wheels use white sidewall pneumatic tires.
Wedding caterers and luxury hotels use them on garden lawns and courtyards for champagne, popsicles, or charcuterie. Municipal event organizers place them inside historic cobblestone plazas and botanical gardens where motor vehicles are prohibited. Marketing agencies use branded fleets for sampling campaigns in shopping centers and airport terminals. The silent operation and zero tailpipe emissions allow use in noise-sensitive and indoor venues.
Before crating, each bike completes a 25 km track test under a 200 kg load to check gear shifting, braking distance, and frame alignment. Eutectic freezer chests undergo a 12-hour thermal leakage test in a 35°C chamber. Draft beverage lines are checked with a 50 PSI pressure drop inspection. After approval, the bike is partially knocked down, wrapped in foam, and packed in steel-reinforced wooden export crates. TUNE provides a 12-month structural factory warranty and assembly guides.
Vintage Pedal Food Bikes can be supplied with CE, ISO 9001, DOT, EPR, COC, and NSF-aligned documents where required. TUNE holds Alibaba Gold Supplier status and has completed regular third-party inspections by SGS and Intertek. Certificate numbers, scope, and validity can be provided before ordering.
Q: Does the bike need any electrical power?
A: No. The ice cream variant uses passive eutectic plates, the beverage variant uses CO2 pressure and glycol cooling, and the water pump is mechanical. It can operate without a battery or generator.
Q: How long does the freezer hold temperature?
A: Up to 9 hours for gelato at -18°C to -22°C, depending on ambient temperature and how often the lid is opened. Plates are frozen overnight before use.
Q: Can it be pushed instead of pedaled?
A: Yes, on the Lightweight Push & Pedal variant. A quick-release pin disengages the drive, turning it into a push cart for indoor use.
Q: What is the maximum load?
A: The frame and running gear are rated for 220 kg total payload, including the operator, equipment, and stock.
Q: What after-sales support is available?
A: TUNE offers a 12-month structural warranty, remote technical support, and shipment of common spare parts such as brake pads, chains, cold plates, and gas fittings. Terms are stated in the contract.
